MINIDOCK™ SLIM Io Connector 30056-160t-F To 30046-160t-F For EDP high-definition screens

Place of Origin China
Brand Name I-PEX
Certification ISO9001
Model Number MINIDOCK™ SLIM 30056-160t-F to 30046-160t-F
Minimum Order Quantity quantity can be negotiable
Price Most favorable
Packaging Details PE inner, carton outer
Delivery Time 2-3 weeks for samples3-4 weeks for massive
Payment Terms T/T, Western Union
Supply Ability 50,000pcs/week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Part Number 30056-160t-F To 30046-160t-F Certification ISO9001
Pitch 0.635mm Pin-out 80 160
High Light

slim io connector


30056-160t-f to 30046-160t-f io connector

Leave a Message
Product Description

MINIDOCK™ SLIM 30056-160t-F to 30046-160t-F Rugged, secure and

reliable I/O connector for multiple applications


                          MINIDOCK (Slim) RECOMMENDED PART NUMBERS


Mating Direction
Width Formula
36.0 ~ 96.10 mm (Plug / Rece) mm
Pin count
80 160
Other Features
With BOSS With screw


Item Specification
Rating Voltage 250V AC (per contact pin)
Rating Amperage (for Contact) 0.5A AC/DC (per contact pin)
Operating Temperature -65°C to +85°C
Operating Humidity 85% max. (non-condensing)
Contact Resistance (for Contact)
- Initial 70mohm max.
- After Test 25mohm max.
Insulation Resistance
- Initial 10.000Mohm min.
- After Test 1.000Mohm min.
Dielectric Withstanding Voltage AC500V 1min
Durability 5,000 Cycles
Mating Force (Initial / After Test)
- Initial 0.9N/pos. max.
- After Test 0.059N/pos. min.
Coplanarity Not specified


                                 OTHER MINIDOCK (Slim) PART NUMBERS


Part Number Description Pin count Part Number
PLUG RIGHT ANGLE 80 30029-080T-01F
160 30046-160T-F
160 30047-160T-01F
VERTICAL 160 30056-160T-F
