2.4KHD OEM DC 50GHz RF Straight Connector Flanged PCB End Solderless
|Place of Origin||China|
|Model Number||RF Straight connector|
|Minimum Order Quantity||quantity can be negotiable|
|Packaging Details||PE inner, carton outer|
|Delivery Time||3-15 days upon receipt of payment|
|Payment Terms||T/T, Western Union|
Contact me for free samples and coupons.
Wechat: 0086 18588475571
If you have any concern, we provide 24-hour online help.x
|Product Name||RF Coaxial Connector||Material||Copper|
|Usage||Telecommunication||Item||Cable Joint Connector|
|Frequency Range||DC - 50 GHz||Apply To||End Launch PCB|
Flanged RF Straight Connector,
50GHz RF Straight Connector,
PCB End RF Coaxial Connector
2.4-KHD Factory OEM DC-50G RF Straight connector flanged PCB
end solderless connector
|VSWR:||1.30 Max @ 50 GHz|
|Frequency Range:||DC - 50 GHz|
|Durability:||≥ 500 Cycles|
|Apply to:||End Launch PCB|
● Impedance: 50 Ω ● Insulation Resistance: 5000 MΩ Min
● Frequency Range: DC - 50 GHz ● Dielectric Withstanding Voltage: 500 Vrms Min (Sea Level)
● VSWR: 1.30 Max @ 50 GHz ● Contact Resistance: ≤ 3 mΩ (Center Contact)
● Insertion Loss: ≤ 0.42 dB @ 50 GHz ≤ 2 mΩ (Outer Contact)
● Mateable with 1.85 mm, V Series ● Center Contact Retention Force: 6 lbs Min
● Durability: ≥ 500 Cycles ● Coupling Torque: 7 - 8 lb-in Recommended
● Temperature Range: -55 ℃ to +85 ℃
Material & Finish
● Body: Stainless Steel, Passivated ● Center Contact: Beryllium Copper, 30 μ" Gold
● Base: Brass, 100 μ" Nickel ● Dielectric: Engineering Plastic, Natural
● High Volume Production Test Stations ● PCB Connections
● Research & Development Labs
● RoHS Compliant ● Good Stability Design ● High Performance
● Solderless & Removable Design (Optional) ● Stainless Steel for Long Mating-cycle Life
Typical Performance Data (@ 25℃)
DUT: 2 PCS 2.4 mm Female, Straight Connectors (Back to Back)
